Porting a CHIP-8 emulator to Rust

I’ve been meaning to learn the Rust language for quite some years and found only now the time to start this endeavor. I must say it has probably been for the best, as the language has clearly matured a lot since the last time I looked into it.

As a first project to try out Rust I ported Laurence Muller’s CHIP-8 emulator to it. It’s a simple C++ project and it took me only a day to port it to Rust.

You can download my port from GitHub.

There’s not much to write about the project itself apart that the original code used GLUT and the port uses SDL2. I also implemented basic audio support, but didn’t work on providing a realistic clock speed.

I can’t yet write something exhaustive about Rust, because I’m still learning it. What I can say up until now is that, apart some minor things which I dislike (snake-case: ugh), it seems fun to program in it. The amount of rules make the programming a bit more challenging, but it pays off in satisfaction once everything builds without complaints.

The only thing I can say is that I can’t clearly see a use-case for Rust. Yes, it’s a solid and secure language which is fun to use. But will it be used in the real world? I can see many use-cases for Go, not so many for Rust. What I hope is for Rust to mature some more and then to become stable, without going down the path to insanity like modern C++.

Batch image manipulation using Python and GIMP

Not a very common topic for me, but I thought it could be neat to mention some tips & tricks. I won’t go into the details of the Python GIMP SDK, most of it can be figured out from the GIMP documentation. I spent a total of one hour researching this topic, so I’m not an expert and I could have made mistakes, but perhaps I can save some effort to others which want to achieve the same results. You can jump to the end of the tutorial to find a nice skeleton batch script if you’re not interested in reading the theory.

To those wondering why GIMP, it’s because I created a new icon for Profiler and wanted to automatize some operations on it in order to have it in all sizes and flavors I need. One of the produced images had to be semi-transparent. So I thought, why not using a GIMP batch command, since anyway GIMP is installed on most Linux systems by default?

Just to mention, GIMP supports also a Lisp syntax to write scripts, but it caused my eyes to bleed profusely, so I didn’t even take into it consideration and focused directly on Python.

Of course, I could’ve tried other solutions like PIL (Python Imaging Library) which I have used in the past. But GIMP is actually nice, you can do many complex UI operations from code and you also have an interactive Python shell to test your code live on an image.

For example, open an image in GIMP, then open the Python console from Filters -> Python-Fu -> Console and execute the following code:

And you’ll see that the image is now halfway transparent. What the code does is to take the first image from the list of open images and sets the opacity of the first layer to 50%.

This is the nice thing about GIMP scripting: it lets you manipulate layers just like in the UI. This allows for very powerful scripting capabilities.

The first small issue I’ve encountered in my attempt to write a batch script, is that GIMP only accepts Python code as command line argument, not the path to a script on disk. According to the official documentation:

GIMP Python All this means that you could easily invoke a GIMP Python plug-in such as the one above directly from your shell using the (plug-in-script- fu-eval …) evaluator:

gimp –no-interface –batch ‘(python-fu-console-echo RUN-NONINTERACTIVE “another string” 777 3.1416 (list 1 0 0))’ ‘(gimp-quit 1)’

The idea behind it is that you create a GIMP plugin script, put it in the GIMP plugin directory, register methods like in the following small example script:

And then invoke the registered method from the command line as explained above.

I noticed many threads on stackoverflow.com where people were trying to figure out how to execute a batch script from the command line. Now, the obvious solution which came to my mind is to execute Python code from the command line which prepends the current path to the sys.path and then to import the batch script. So I searched and found that solution suggested by the user xenoid in this stackoverflow thread.

So the final code for my case would be:

And:

What took me most to understand was to call the method merge_visible_layers before saving the image. Initially, I was trying to do it without calling it and the saved image was not transparent at all. So I thought the opacity was not correctly set and tried to do it with other methods like calling gimp_layer_set_opacity, but without success.

I then tried in the console and noticed that the opacity is actually set correctly, but that that information is lost when saving the image to disk. I then found the image method flatten and noticed that the transparency was retained, but unfortunately the saved PNG background was now white and no longer transparent. So I figured that there had to be a method to obtain a similar result but without losing the transparent background. Looking a bit among the methods in the SDK I found merge_visible_layers. I think it’s important to point this out, in case you experience the same issue and can’t find a working solution just like it happened to me.

Now we have a working solution, but let’s create a more elegant one, which allows use to use GIMP from within the same script, without any external invocation.

We can now call our function simply like this:

Which looks very pretty to me.

I could go on showing other nice examples of image manipulation, but the gist of the tutorial was just this. However, GIMP has a rich SDK which allows to automatize very complex operations.

Time Travel: Running Python 3.7 on XP

To restart my career as a technical writer, I chose a light topic. Namely, running applications compiled with new versions of Visual Studio on Windows XP. I didn’t find any prior research on the topic, but I also didn’t search much. There’s no real purpose behind this article, beyond the fact that I wanted to know what could prevent a new application to run on XP. Our target application will be the embedded version of Python 3.7 for x86.

If we try to start any new application on XP, we’ll get an error message informing us that it is not a valid Win32 application. This happens because of some fields in the Optional Header of the Portable Executable.

Most of you probably already know that you need to adjust these fields as follows:

MajorOperatingSystemVersion: 5
MinorOperatingSystemVersion: 0
MajorSubsystemVersion: 5
MinorSubsystemVersion: 0

Fortunately, it’s enough to adjust the fields in the executable we want to start (python.exe), there’s no need to adjust the DLLs as well.

If we try run the application now, we’ll get an error message due to a missing API in kernel32. So let’s turn our attention to the imports.

We have a missing vcruntime140.dll, then a bunch of “api-ms-win-*” DLLs, then only python37.dll and kernel32.dll.

The first thing which comes to mind is that in new applications we often find these “api-ms-win-*” DLLs. If we search for the prefix in the Windows directory, we’ll find a directory both in System32 and SysWOW64 called “downlevel”, which contains a huge list of these DLLs.

As we’ll see later, these DLLs aren’t actually used, but if we open one with a PE viewer, we’ll see that it contains exclusively forwarders to APIs contained in the usual suspects such as kernel32, kernelbase, user32 etc.

There’s a MSDN page documenting these DLLs.

Interestingly, in the downlevel directory we can’t find any of the files imported by python.exe. These DLLs actually expose C runtime APIs like strlen, fopen, exit and so on.

If we don’t have any prior knowledge on the topic and just do a string search inside the Windows directory for such a DLL name, we’ll find a match in C:\Windows\System32\apisetschema.dll. This DLL is special as it contains a .apiset section, whose data can easily be identified as some sort of format for mapping “api-ms-win-*” names to others.

Searching on the web, the first resource I found on this topic were two articles on the blog of Quarkslab (Part 1 and Part 2). However, I quickly figured that, while useful, they were too dated to provide me with up-to-date structures to parse the data. In fact, the second article shows a version number of 2 and at the time of my writing the version number is 6.

Just for completeness, after the publication of the current article, I was made aware of an article by deroko about the topic predating those of Quarkslab.

Anyway, I searched some more and found a code snippet by Alex Ionescu and Pavel Yosifovich in the repository of Windows Internals. I took the following structures from there.

The data starts with a API_SET_NAMESPACE structure.

Count specifies the number of API_SET_NAMESPACE_ENTRY and API_SET_HASH_ENTRY structures. EntryOffset points to the start of the array of API_SET_NAMESPACE_ENTRY structures, which in our case comes exactly after API_SET_NAMESPACE.

Every API_SET_NAMESPACE_ENTRY points to the name of the “api-ms-win-*” DLL via the NameOffset field, while ValueOffset and ValueCount specify the position and count of API_SET_VALUE_ENTRY structures. The API_SET_VALUE_ENTRY structure yields the resolution values (e.g. kernel32.dll, kernelbase.dll) for the given “api-ms-win-*” DLL.

With this information we can already write a small script to map the new names to the actual DLLs.

This code can be executed with Cerbero Profiler from command line as “cerpro.exe -r apisetschema.py”. These are the first lines of the produced output:

Going back to API_SET_NAMESPACE, its field HashOffset points to an array of API_SET_HASH_ENTRY structures. These structures, as we’ll see in a moment, are used by the Windows loader to quickly index a “api-ms-win-*” DLL name. The Hash field is effectively the hash of the name, calculated by taking into consideration both HashFactor and HashedLength, while Index points to the associated API_SET_NAMESPACE_ENTRY entry.

The code which does the hashing is inside the function LdrpPreprocessDllName in ntdll:

Or more simply in C code:

As a practical example, let’s take the DLL name “api-ms-win-core-processthreads-l1-1-2.dll”. Its hash would be 0x445B4DF3. If we find its matching API_SET_HASH_ENTRY entry, we’ll have the Index to the associated API_SET_NAMESPACE_ENTRY structure.

So, 0x5b (or 91) is the index. By going back to the output of mappings, we can see that it matches.

By inspecting the same output, we can also notice that all C runtime DLLs are resolved to ucrtbase.dll.

I was already resigned at having to figure out how to support the C runtime on XP, when I noticed that Microsoft actually supports the deployment of the runtime on it. The following excerpt from MSDN says as much:

If you currently use the VCRedist (our redistributable package files), then things will just work for you as they did before. The Visual Studio 2015 VCRedist package includes the above mentioned Windows Update packages, so simply installing the VCRedist will install both the Visual C++ libraries and the Universal CRT. This is our recommended deployment mechanism. On Windows XP, for which there is no Universal CRT Windows Update MSU, the VCRedist will deploy the Universal CRT itself.

Which means that on Windows editions coming after XP the support is provided via Windows Update, but on XP we have to deploy the files ourselves. We can find the files to deploy inside C:\Program Files (x86)\Windows Kits\10\Redist\ucrt\DLLs. This path contains three sub-directories: x86, x64 and arm. We’re obviously interested in the x86 one. The files contained in it are many (42), apparently the most common “api-ms-win-*” DLLs and ucrtbase.dll. We can deploy those files onto XP to make our application work. We are still missing the vcruntime140.dll, but we can take that DLL from the Visual C++ installation. In fact, that DLL is intended to be deployed, while the Universal CRT (ucrtbase.dll) is intended to be part of the Windows system.

This satisfies our dependencies in terms of DLLs. However, Windows introduced many new APIs over the years which aren’t present on XP. So I wrote a script to test the compatibility of an application by checking the imported APIs against the API exported by the DLLs on XP. The command line for it is “cerpro.exe -r xpcompat.py application_path”. It will check all the PE files in the specified directory.

I had to omit the contents of the apisetschema global variable for the sake of brevity. You can download the full script from here. The system32 directory referenced in the code is the one of Windows XP, which I copied to my desktop.

And here are the relevant excerpts from the output:

We’re missing 5 APIs from kernel32.dll and 2 from ws2_32.dll, but the Winsock APIs are imported just by _socket.pyd, a module which is loaded only when a network operation is performed by Python. So, in theory, we can focus our efforts on the missing kernel32 APIs for now.

My plan was to create a fake kernel32.dll, called xernel32.dll, containing forwarders for most APIs and real implementations only for the missing ones. Here’s a script to create C++ files containing forwarders for all APIs of common DLLs on Windows 10:

It creates files like the following kernel32.cpp:

The comment on the right (“// XP”) indicates whether the forwarded API is present on XP or not. We can provide real implementations exclusively for the APIs we want. The Windows loader doesn’t care whether we forward functions which don’t exist as long as they aren’t imported.

The APIs we need to support are the following:

GetTickCount64: I just called GetTickCount, not really important
GetFinalPathNameByHandleW: took the implementation from Wine, but had to adapt it slightly
InitializeProcThreadAttributeList: took the implementation from Wine
UpdateProcThreadAttribute: same
DeleteProcThreadAttributeList: same

I have to be grateful to the Wine project here, as it provided useful implementations, which saved me the effort.

I called the attempt at a support runtime for older Windows versions “XP Time Machine Runtime” and you can find the repository here. I compiled it with Visual Studio 2013 and cmake.

So that we have now our xernel32.dll, the only thing we have to do is to rename the imported DLL inside python37.dll.

Let’s try to start python.exe.

Awesome.

Of course, we’re still not completely done, as we didn’t implement the missing Winsock APIs, but perhaps this and some more could be the content of a second part to this article.

NTCore revamped

After over a decade, I finally took two afternoons to revamp this personal web-page and to merge the content of the old NTCore page with the content of its blog (rcecafe.net). All the URLs of the old web-page and blog have been preserved in the process.

The people who voted for this on Twitter are the guilty ones.

You know who you are.

Ctor conflicts

Perhaps the content of this post is trivial and widely known(?), but I just spent some time fixing a bug related to the following C++ behavior.

Let’s take a look at this code snippet:

The output of the code above is:

Whether we compile it with VC++ or g++, the result is the same.

The problem is that although the struct or class is declared locally the name of the constructor is considered a global symbol. So while the allocation size of the struct or class is correct, the constructor being invoked is always the first one encountered by the compiler, which in this case is the one which prints ‘apple’.

The problem here is that the compiler doesn’t warn the user in any way that the wrong constructor is being called and in a large project with hundreds of files it may very well be that two constructors collide.

Since namespaces are part of the name of the symbol, the code above can be fixed by adding a namespace:

Now the correct constructor will be called.

I wrote a small (dumb) Python script to detect possible ctor conflicts. It just looks for struct or class declarations and reports duplicate symbol names. It’s far from perfect.

In my opinion this could be handled better on the compiler side, at least by giving a warning.

ADDENDUM: Myria ‏(@Myriachan) explained the compiler internals on this one on twitter:

I’m just surprised that it doesn’t cause a “duplicate symbol” linker error. Symbol flagged “weak” from being inline, maybe? […] Member functions defined inside classes like that are automatically “inline” by C++ standard. […] The “inline” keyword has two meanings: hint to compiler that inlining machine code may be wise, and making symbol weak. […] Regardless of whether the compiler chooses to inline machine code within calling functions, the weak symbol part still applies. […] It is as if all inline functions (including functions defined inside classes) have __declspec(selectany) on them, in MSVC terms. […] Without this behavior, if you ever had a class in a header with functions defined, the compiler would either have to always inline the machine code, or you’d have to use #ifdef nonsense to avoid more than one .cpp defining the function.

The explanation is the correct one. And yes, if we define the ctor outside of the class the compiler does generate an error.

The logic mismatch here is that local structures in C do exist, local ctors in C++ don’t. So, the correct struct is allocated but the wrong ctor is being called. Also, while the symbol is weak for the reasons explained by Myria, the compiler could still give an error if the ctor code doesn’t match across files.

So the rule here could be: if you have local classes, avoid defining the ctor inside the class. If you already have a conflict as I did and don’t want to change the code, you can fix it with a namespace as shown above.
